Hiblow HP-120LL Linear Air Pump for Pond Aeration
The Hiblow HP-120LL can be used to aerate ponds up to 1.25 acres in size and up to 8 feet deep. The Hiblow linear air pumps offer very quiet operation and are extremely energy efficient when compared with other pond aeration compressors. The Hiblow linear air pump is by far the best option for small sized / shallow depth ponds.We recommend using 3/8'' inside diameter or larger tubing with the Hiblow HP-120LL
In Stock
Item #:HP120LLP
Manufacturer:PondPlus+
Hiblow HP-120LL Specifications
- 5.2 cfm (cubic feet per minute) Maximum Air Flow (@ 0 PSI)
- 3.5 cfm @ 8 FT of Water Depth (3.5 PSI)
- 4.3 PSI Maximum Continuous Operating Pressure
- 120VAC, 60 Hz, 1.4A, 100 Watts
- 45 dBA Measured @ 1 meter
- Dimensions: 10.1'' L x 7.9'' W x 8.8'' H
- Condition: NEW
- 1 Year Warranty
Hiblow HP-120LL Airline Size Requirements:
- 3/8'' ID line can be used up to 200 feet
- 1/2'' ID line can be used up to 500 feet
- We do not recommend the use of more than 500 total feet of airline with the Hiblow HP-120LL
Hiblow HP120LL Frequently Asked Questions
Below are some frequently asked questions about the Hiblow HP-120LL linear air pump. If you have further questions, call our customer support staff toll free at 1-877-925-5132 or email sales@septicsolutions.com!
What size pond can I aerate with the HP120LL?
The Hiblow HP-120LL can be used to aerate small ponds up to 1.25 acre in surface area size and up to 8 feet deep. Using this pump at depths greater than 8 feet will cause an extreme loss in volume of airflow and will greatly reduce the overall life of the compressor.
What is the difference between the HP120 and the HP120LL?
The new Hiblow HP-120LL is an improved long life version of the Hiblow HP-120. The original Hiblow HP-120 would average around 2-3 years of diaphragm life. This new and improved Long Life version should see around 5 years out of diaphragms.
Can this air pump be left out in the weather or does it need a weatherproof cover?
The Hiblow HP-120LL is considered weatherproof and can be installed without a cover. However we highly recommend using an air pump housing to further protect the unit from the elements. Click here to view the air pump housing options.
Does this air pump come with the fitting to connect to my alarm or control box?
Yes. The Hiblow HP-120LL comes with an optional brass barb fitting that will allow you to connect a 1/8'' airline from the air pump to your alarm or control box.
Does this product come with a manufacturer's warranty?
Yes. The Hiblow HP-120LL comes with a standard manufacturer's warranty of 1 year.
What size airline should I use with the Hiblow HP-120LL?
The Hiblow HP-120LL air pump is designed to be used with 3/8'' ID airline or larger. It comes with a rubber 90 coupling connector and hose clamps.
