Alderon Flex Panel Duplex Time Dose & Demand Dose Control Panel with Solid Door and Alarm Beacon(120/230V, 0-15FLA)

Print

SOLID DOOR, EXTERNAL ALARM BEACON, MOTOR CONTACTOR

The Alderon Flex Panel Duplex control panel is designed to control and monitor a lift station with two submersible pumps using either demand dose or timed dose functionality. The Flex Panel includes pump circuitry, high water alarm, and 3 mechanical float switches the can be programmed to your desired functionality.

The Alderon Flex panels feature a revolutionary menu system that enables maximum field configuration and statistics tracking. A convenient setup wizard is included in the menu to get the panel configured to your desired functionality in a few simple steps. The Alderon Flex panel comes with a solid outer door, an external alarm beacon, and the pumps are started by a heavy duty motor contactor.

Made In USANEMA 4XUL Listed

In Stock

$1449.00MSRP: $2075.00

Item #:2010863

Manufacturer: Alderon

FLEX PANEL DUPLEX SPECIFICATIONS

  • Controls Two Submersible Pumps at 120/230VAC, Single Phase, 0-15 FLA
  • 120/230VAC Power Input for Pumps, 120VAC Power Input for Alarm/Control Circuit
  • Includes (3) Mechanical Floats w/ 20ft Cords
  • Solid Door with External Alarm Beacon
  • Demand Dose Float Functions: Off, Lead On, Lag On, Alarm
  • Timed Dose Float Functions: Low Alarm / Redundant Off, Timer Enable, Peak Timer, High Alarm
  • Automatically Alternates Pumps Each Cycle
  • Programmable for Time Dosing or Demand Dosing
  • Advanced Menu System to Maximum Field Configuration Options
  • Simple Setup Wizard in the Menu, Configures in minutes!
  • High decibel alarm buzzer (100 dB)
  • Pump Hand/Off/Auto Toggle with Indicator Light
  • Exterior Test Toggle Switch to Test Alarm and Quick View Pump/Alarm Statistics
  • Field wiring terminal strips
  • Conformal Coated Circuit Boards for Reliable Thermal and Moisture Protection
  • Built-In Printed Circuit Board Surge Protection
  • IEC Motor Contactor (1,000,000 cycle rating)
  • Motor Circuit Breaker
  • Automatic Resettable Alarm and Control Fuses
  • Pad-Lockable NEMA 4X Enclosure, UL 508A Listed
  • Dimensions: 10.00'' W x 11.25'' T x 5.00'' D
  • Three Year Manufacturer's Warranty

FLEX POWER PAK DUPLEX ADVANCED FEATURES

  • Easily Change Configurations
    • Demand Dosing
    • Timed Dosing (Low Alarm/Redundant Off, Timer Enable, Peak Timer, High Alarm)
    • Accepts Transducer
    • Enable Pump Exercising
    • Seal Fail Alarm or Pump Shutdown
  • Advanced Pump Station Statistic Tracking
    • Pump Elapsed Time
    • Min/Max/Avg Pump Run Times
    • Pump Cycle Counter
    • Total Gallons Pumped
    • High Level Stats
    • Many More
  • Multi-Color Super Bright LED Light Strip
    • Green = Normal
    • Red = Alarm
    • Blue = Pump Run
    • Red/Yell = Sensor Error
    • Many More
  • Multiple Sensor Options
    • Field accepts up to 5 Float Inputs to Allow for Low Alarm and Auxiliary Switch Options
    • Configure Float, Auxiliary or 4- 20 mA Submersible Transducer

FLEX DUPLEX PANEL APPLICATIONS

  • NEMA 4X Enclosure for Outdoor Installations
  • Used to control a pump station with a two submersible pumps
  • Time Dosing Controller allows for scheduled dosing and flow equalization
  • Programmable Smart Controller includes Elapsed Time Meter and Cycle Counter
  • Programmable Smart Controller keeps record of Time Overrides and High Water Alarms

WHY USE TIME DOSING?

Time Dosing control panels are used to control the amount of water a submersible pump can push to the secondary system over a period of time. The Simplex and Duplex control panels listed above are considered On Demand or Demand Dose systems. This means the pump will run when it needs to based upon the float switch in the tank. Time Dosing or Timed Dose panels use a Repeat Cycle timer in which an ON cycle and an OFF cycle is set for the pump and the timer follows that cycle repeatedly.

The reason for time dosing is to equalize the flow of water to the secondary system. In certain applications large amounts of water can be used in a short period of time. This is very hard on a septic system. With a Time Dosing control panel, you can equalize that flow by spreading it out throughout a longer period of time. The Repeat Cycle Timer will dose the system by running the pump short periods of time throughout the day versus an On Demand system (like the Simplex and Duplex Panels Above) that will pump a large amount of water all at once.

Our Time Dosing Control Panels are available in 120V and 230V. We have them for both Simplex and Duplex applications.
