Alderon Go2 Simplex Submersible Pump Control Panel (120/230V, 0-20FLA)

Print

The Alderon Go2 Simplex Pump Control is designed to control and monitor a single submersible pump. The Go2 series panels include pump circuitry, high water alarm, and 3 mechanical float switches for "OFF", "ON", and "ALARM" controls.

The Go2 panel utilizes a power relay instead of a motor contactor to turn the submersible pump on and off and includes a Hand/Off/Auto toggle switch for the pump.

Made In USANEMA 4XUL Listed

In Stock

$499.00MSRP: $685.00

Item #:2010535

Manufacturer: Alderon

Alderon Go2 Control Panel Features

  • 120/230VAC, Single Phase, 0-20 FLA
  • Pump Circuit Breaker
  • Automatic Resettable Alarm and Control Fuse
  • Two Power Inputs: 120/230V for Pump Power, 120V for Control Power
  • (3) Mechanical Floats w/ 15ft Cords
  • Multi-Color LED Beacon: Green = Normal, Green Flash = Pump Run, Red Flash = High Water
  • High decibel audible buzzer (100 dB)
  • Status LEDs - Pump Run Indicator, Float Activated Indicator
  • Float Out of Sequence Alarm
  • Pump Hand/Off/Auto toggle switch
  • Alarm On/Test/Mute heavy duty toggle
  • Power Relay (100,000 cycle rating)
  • Auxiliary Dry Contracts - NO/NC
  • Built-In Circuit Board Lightning and Surge Protection
  • Color Coded Wiring, Field Wiring Terminal Strips
  • NEMA 4X Rated Enclosure, UL 508A Listed
  • Three Year Warranty

Alderon Go2 Control Panel Applications

The Alderon Go2 Simplex Pump Station control panel can operate a pump station with a single submersible pump. This dual voltage control panel can operate a single submersible pump up to 20 FLA at either 120VAC or 230 VAC. The Go2 Simplex Control Panel features separate circuits for the submersible pump and the control/alarm portion of the panel. This means that if the submersible pump fails and trips its circuit breaker, the alarm will still be functional. It also includes the standard features of most simplex control panels which include the HOA switch, Pump Run Indicator Light, Alarm Run/Test/Mute Switch, and the Audible Buzzer and Visual Light Alarms.

  • Sewage Pump/Lift Stations
  • Effluent Pump/Lift Stations
  • Controlling and Monitoring Any 120V or 230V Pump up to 20FLA

Alderon Go2 Simplex Control Panel Downloadable Documents

FileName
Go2 1P Simplex Series Quick Start GuideViewDownload
Go2 1P Simplex Series SpecificationViewDownload
