Liberty 2460-Series Simplex Sewage Grinder Pump Station

Print

50 MAX GPM, 110 FT MAX HEAD, 1-1/4" DISCHARGE

For residential and commercial applications, the 2460LSG is a complete factory assembled simplex grinder package featuring the LSG200-Series 2 HP Omnivore® grinder pump. All internal brackets, floats, guide-rail base and discharge piping is pre-installed at the factory saving hours of labor at the job site.

For residential and commercial applications, the 2448LSG is a complete factory assembled simplex grinder package featuring the LSG200-Series 2 hp Omnivore® grinder pump. All internal brackets, floats, guide-rail base and discharge piping is pre-installed at the factory saving hours of labor at the job site. - See more at: http://www.libertypumps.com/Product/2448-Series#sthash.0Oi8bu8N.dpuf
Assembled In USA Powder Coated Tough

Ships In 5-7 Business Days

$3749.00 MSRP: $52.00

Item #:2460LSG202-36

Manufacturer: Liberty Pumps

Liberty 2460 Simplex Pump Station

Omnivore LSGX-200 Grinder Pump Specifications

  • Model LSGX202A
  • 2.0 HP, 230VAC, 15.0A, 60 Hz
  • 25 GPM @ 100ft of Head Pressure
  • Shut Off: 185ft, Max GPM: 39
  • 1-1/4'' NPT Vertical Female Discharge
  • Heavy Duty Cast Iron Construction
  • Patented V-Slice Cutter Technology
  • Shreds Difficult Solids Such As Feminine Products, Wipes, Rags, Etc.
  • Twin Stainless Steel Impellers Driving Flow To Maximum Heads of 180 feet
  • Includes Quick-Disconnect 25' Power Cord with Plug
  • Includes 25' Wide Angle Mechanical Float Switch with Piggyback Plug
  • Dimensions: 9.5'' L x 9.5'' W x 19.5'' T
  • Three Year Warranty

24x60 Fiberglass Basin Specifications

  • Pre-Mounted Floats For Pump Control & Alarm
  • 4'' Fiberglass Hub with 4'' Rubber Pipe Seal
  • 1-1/4'' Discharge
  • Pre-Assembled Galvanized Guide Rail System
  • Pre-Assembled Schedule 80 PVC Discharge Piping with Ball Valve
  • Integral Check Valve
  • Anti-Flotation Collar
  • Structural Foam Cover - 1000lb Load Rating
  • NEMA 4X Junction Box For Electrical Connections
  • Stainless Steel Lift Chain For Pump

SX-Series Simplex Control Panel Specifications

  • HOA Switch
  • NEMA 4X Enclosure
  • Circuit Breaker
  • Visual and Audible Alarm
  • Pump Run Indicator Light
  • Auxiliary Contacts
  • Three Level Control Floats
