Alderon Check It Duplex Control Panel (120/240V, 0-20FLA)


The Alderon Check It™ Duplex Control Panel is designed to control and monitor a pump station with two submersible pumps. This item includes circuitry for 2 submersible pumps, a built-in high water alarm, the Check It™ Self Diagnosing system, and 3 mechanical float switches for "OFF", "LEAD ON", and "ALARM" controls. A fourth float switch can be added for "LAG ON" control.

Made In USANEMA 4XUL Listed

In Stock

$1035.00MSRP: $1150.00

Item #:2013

Manufacturer: Alderon

Alderon Duplex Control Specifications

  • 120/230VAC, Single Phase, 0-20 FLA
  • (3) Mechanical Floats w/ 20ft Cords for OFF, LEAD ON, and ALARM controls
  • A Fourth Float Can Be Added for LAG ON control
  • 360 Degree Red Alarm Light, High Decible Audible Buzzer (100 dB)
  • Check It™ Self Diagnosing System - One Touch Troubleshooting
  • Alternating Relay - Automatically Alternates Pumps Each Cycle
  • Pump Run Indicator Light
  • Pump HAND / OFF / AUTO Toggle Switch
  • Alarm RUN / TEST / MUTE Toggle Switch
  • IEC Motor Contactors (2,000,000 cycle rating)
  • Motor Circuit Breaker
  • 3 Amp Control Fuse
  • Color Coded Wiring / Field Wiring Terminal Strips
  • Dimensions: 12.00'' W x 16.00'' T x 8.0'' D
  • NEMA 4X Enclosure, UL 508A Listed
  • Three Year Warranty

Alderon Duplex Control Applications

  • NEMA 4X Enclosure for Outdoor Installations
  • Used to control a pump station with two submersible pumps
  • Monitors liquid levels and gives alarm for high water
  • Alternating relay automatically switches pump every cycle
  • LAG ON options allows the secondary pump to come on in event the primary pump malfunctions
  • Check It™ One Touch Diagnostics - Troubleshoot your problem with one push of a button!
