• Alderon Go2 Totalizer WiFi Enabled Timed or Demand Dose Simplex Control Panel (120/230V, 0-20 FLA) - Part Number 2012793
  • Alderon Go2 Totalizer WiFi Enabled Timed or Demand Dose Simplex Control Panel (120/230V, 0-20 FLA) - Part Number 2012793
  • Product Video
    )

Alderon Go2 Totalizer WiFi Enabled Timed or Demand Dose Simplex Control Panel (120/230V, 0-20 FLA)

Print

The Alderon Go2 Totalizer WiFi Enabled simplex control panel is designed to control and monitor a single submersible pump using either demand dose or timed dose functionality. Includes pump circuitry, high water alarm, and 3 mechanical float switches the can be programmed to your desired functionality.

The Alderon Go2 Totalizer panels feature a revolutionary menu system that enables maximum field configuration and statistics tracking. A convenient setup wizard is included in the menu to get the panel configured to your desired functionality in a few simple steps.

This panel is Vizzylink WiFi enabled for remote monitoring and receiving text and email alerts for system conditions.

Made In USANEMA 4XUL Listed

Coming Soon!

$899.00MSRP: $1309.00

Item #:2012793

Manufacturer: Alderon

THIS ITEM WILL BE AVAILABLE SOON! CALL (877)-925-5132 TO BE NOTIFIED WHEN THIS ITEM IS AVAILABLE FOR PURCHASE.

GO2 TOTALIZER SIMPLEX SPECIFICATIONS

  • Model: GO2T1S230H20-CT6V1+3AGHPR20
  • Controls Pumps at 120/230VAC, Single Phase, 0-20 FLA
  • Single Power Input that splits to Pump Power and Control Power within the panel
  • 25 Amp Pump Circuit Breaker, 10 Amp Control Circuit Breaker
  • Includes (3) Mechanical Floats w/ 20ft Cords
  • Vizzylink WiFi Enabled for Remote Monitoring
  • Programmable for Time Dosing or Demand Dosing
  • Advanced Menu System to Maximum Field Configuration Options
  • Simple Setup Wizard in the Menu, Configures in minutes!
  • High decibel alarm buzzer (100 dB)
  • Pump Hand/Off/Auto Toggle with Indicator Light
  • Lever style Terminal Blocks - Screwdriver-less installation
  • Conformal Coated Circuit Boards for Reliable Thermal and Moisture Protection
  • Built-In Printed Circuit Board Surge Protection
  • Double-Pole Hybrid Solid State Relay (1,000,000 cycle rating)
  • Automatic Resettable Alarm and Control Fuses
  • Includes Auxiliary Dry Contacts (Normally Open/Normally Closed activated for any Alarm or Power Loss
  • Pad-Lockable NEMA 4X Enclosure, UL 508A Listed
  • Dimensions: 10.00'' W x 8.00'' T x 4.00'' D
  • Three Year Manufacturer's Warranty

VIZZYLINK WIFI ENABLED

  • Remote monitoring through Vizzy Portal
  • Must be installed within range of internet connected WiFi
  • Receive Text and Email Alerts for System Conditions
  • Can be accessed via Web Browser
  • Mobile App Available on both Android and Apple IOS Devices

GO2 TOTALIZER ADVANCED FEATURES

  • Easily Change Configurations
    • Demand Dosing
    • Timed Dosing (Low Alarm/Redundant Off, Timer Enable, Peak Timer, High Alarm)
  • Digital Amp Meter
    • Display real-time pump running amps
    • Track amperage statistics: High, Low, Min/Max/Average
    • Used for Pump and Relay failure detection
  • Advanced Pump Station Statistic Tracking
    • Pump Elapsed Time
    • Min/Max/Avg Pump Run Times
    • Pump Cycle Counter
    • Total Gallons Pumped
    • High Level Stats
    • Many More
  • Multi-Color Super Bright LED Light Strip
    • Green = Normal
    • Red = Alarm
    • Blue = Pump Run
    • Red/Yell = Sensor Error
    • Many More
  • Multiple Sensor Options
    • Field accepts up to 4 Float Inputs to Allow for Low Alarm and Auxiliary Switch Options

Alderon Go2 WiFi Enabled Simplex Time or Demand Dose Control Panel Videos

Alderon Go2 Totalizer Menu Overview

Product Video
)

Alderon Go2 WiFi Enabled Simplex Time or Demand Dose Control Panel Downloadable Documents

FileName
GO2T1SXXX-CT6 Install GuideViewDownload
GO2T1SXXX-CT6 SpecificationViewDownload
