Observer 500 Series Indoor/Outdoor High Water Alarm with 15' Mechanical Float Switch

Print

The Observer 500 Series High Water Alarm is a reliable and versatile solution for monitoring liquid levels in septic tanks, pump stations, holding tanks, and other applications. Designed for both indoor and outdoor use, this alarm features a NEMA 4X watertight enclosure, ensuring durability in harsh weather conditions.

Equipped with a 15' mechanical float switch and a 6' power cord, the Observer 500 provides an audible and visual alert to prevent costly backups and overflows.

Made In USANEMA 4XUL Listed

In Stock

$174.00MSRP: $199.00

Item #:10A500

Manufacturer: SPI

Observer 500 Alarm Specifications

  • Indoor/Outdoor Alarm with Light and Audible Buzzer
  • 15ft Mechanical Float Switch with Pipe Mount
  • 6ft Power Cord with Plug For Easy Installation
  • Alarm Test and Mute Switch
  • Audible Buzzer: 85 dB @ 10 feet
  • NEMA 4x Watertight Enclosure
  • 120VAC, 60Hz
  • Two Year Limited Warranty

Observer 500 Alarm Features

  • Indoor/Outdoor Versatility: NEMA 4X watertight enclosure for reliable performance in any environment.
  • Audible and Visual Alerts: High-decibel buzzer and bright alarm light activate when high water levels are detected.
  • 15' Mechanical Float Switch: Triggers the alarm when liquid levels rise, ensuring timely notifications.
  • 6' Power Cord: Simplifies installation with a standard 120 VAC plug.
  • Easy Installation: Can be mounted on a post, wall, or pedestal for flexible setup.
  • Automatic Reset: System resets itself once the high water condition is resolved.
  • Durable Design: Built to withstand the demands of septic and wastewater applications.

Observer 500 Alarm Applications

  • Septic Tanks: Alerts homeowners to high water levels to prevent system backups
  • Pump Stations: Monitors liquid levels to ensure proper pump operation
  • Holding Tanks: Provides early warning of potential overflows
  • Sump Pits and Other Systems: Ideal for any application requiring liquid level monitoring.

Installation Overview

  1. Mount the Alarm Box: Secure the NEMA 4X enclosure on a post, outdoor wall, or pedestal.
  2. Install the Float Switch: Place the 15' mechanical float switch inside the septic tank or pump chamber, ensuring it can move freely to detect high water levels.
  3. Connect the Float Switch: Run the float switch wire to the alarm box and connect it to the designated terminals.
  4. Plug in the Power Cord: Insert the 6' power cord into a standard 120 VAC outlet.
  5. Test the System: Lift the float switch manually to verify the audible buzzer and visual light activate. Ensure the system resets when the float is lowered.


Observer 500 Series High Water Alarm Downloadable Documents

FileName
10A500_InstallViewDownload
10A500_SpecViewDownload
