500 Gallon Duplex Fiberglass Pump Station with (2) 1.0 HP Liberty Sewage Ejector Pumps and Alternating Control Panel

Print

FOR RAW SEWAGE PUMPING APPLICATIONS

This 500 gallon fiberglass duplex pump station comes pre-assembled and ready to install with all of the components needed to install a direct burial in-ground duplex sewage lift station. The typical application for this package is to pump sewage and wastewater from a household to the septic tank or aerobic system.

PUMP STATION FEATURES:

  • 70'' x 67'' Basin with 500 Gallon Capacity
  • (2) 1.0 HP Liberty Sewage Pumps with 2'' Discharge
  • 120 GPM @ 25ft of Head, Shut Off: 39ft of Head
  • 230VAC, 8.0A, 60Hz, 1 Phase
  • SPI SDC12B Duplex Control Panel with Alarm

THIS ITEM SHIPS VIA LTL FREIGHT. PLEASE CALL 1-877-925-5132 TO GET A SHIPPING QUOTE OR PLACE AN ORDER.

Built To Order Within 1-2 Business Days

$5079.00MSRP: $5529.00

Item #:500FPT-LE102DUP

Manufacturer: Septic Solutions

THIS ITEM SHIPS LTL FREIGHT.
PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

500 GALLON FIBERGLASS TANK

  • 70'' Diameter, 67'' Tall
  • Heavy Duty Fiberglass Designed For Direct Burial
  • 24'' Diameter Polylok Access Cover
  • Risers Available To Bring Access To Grade
  • 4'' Inlet Hole with Grommet
  • 2'' SCH 40 Discharge Pipe Sealed with Grommet
  • Cord Seals For Power and Float

LIBERTY 1.0 HP SEWAGE EJECTOR PUMP

  • Model LE102A
  • 1.0 HP, 230VAC, 8.0A, 60 Hz
  • 120 GPM @ 20ft of Head Pressure
  • Shut Off: 39ft, Max GPM: 190
  • 2'' NPT Vertical Female Discharge, 2'' Solids Handling
  • Heavy Duty Cast Iron Construction
  • 2-Vane Cast Iron Impeller
  • Includes Quick-Disconnect 10' Power Cord with Plug
  • Includes 10' Wide Angle Mechanical Float Switch with Piggyback Plug
  • Dimensions: 12.6'' L x 9.0'' W x 15.3'' T
  • Three Year Warranty

#50A506 DUPLEX CONTROL PANEL

  • 120/240VAC, Single Phase, 0-20 FLA
  • (3) Mechanical Floats w/ 20ft Cords
  • 360 degree red alarm light, High decible audible buzzer (100 dB)
  • Automatic Alternating Relay
  • Pump run light indicator
  • Pump Hand/Off/Auto heavy duty toggle
  • Alarm On/Test/Mute heavy duty toggle
  • Field wiring terminal strips
  • Two 2-pole definite purpose contactors (100,000 cycle rating)
  • Motor circuit breaker
  • 3 amp control/alarm fuses
  • Color Coded Wiring
  • Dimensions: 16.25'' W x 19.63'' T x 6.25'' D
  • NEMA 4X Enclosure, UL 508A Listed
  • Two Year Limited Warranty
This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.

    500 Gallon Duplex Pump Station with (2) 1.0 HP Sewage Pumps Downloadable Documents

    FileName
    500FiberglassTank_SpecViewDownload
    50A506_InstallViewDownload
    50A506_SpecViewDownload
    LE102A_FeaturesViewDownload
    LE102A_SpecificationsViewDownload
    Pump-Station-Backfill-InstructionsViewDownload
