Elevator Sump System with Little Giant 1/2 HP Sump Pump and Oil Detection System

Print

1/2 HP SUMP PUMP, 36 FT MAX HEAD, 67 MAX GPM

The Elevator Sump Water Removal System is used in elevator sump pits to remove water while retaining oil and other hydrocarbons. Water and oil fill the elevator sump pit. As the sump is filling, the oil will float on top of the water. This layer of oil will not be pumped from the tank. The water underneath the oil will be pumped out through the discharge pipe to the sewer or other proper disposal area.

In Stock

$1599.00MSRP: $2350.00

Item #:ELV10EC-7410

Manufacturer: Septic Solutions

Little Giant 10EC Series Specifications

  • 1/2 HP, 115VAC, 6.5A, 60 Hz
  • 67 GPM @ 5ft of Head Pressure
  • Shut Off: 36ft, Max GPM: 67
  • 1-1/2'' NPT Vertical Female Discharge, 3/4'' Solids Handling
  • Complete Heavy Duty Cast Iron Construction
  • Dimensions: 8.79'' L x 8.48'' W x 10.90'' T
  • Three Year Warranty

    Oil Alert™ Control Features

    • 120 VAC, Single Phase, 0-15 FLA
    • One Preset Level Sensor For Easy Installation
    • Operates With All Pumps Approved for Sump Pits
    • Remote Alarm Included
    • NEMA Type I Enclosure
    • ASME A17.1 COMPLIANT
    • Dimensions: 9.75'' H  x 5.02'' W x 5.25'' D

    Oil Alert™ Operation

    On liquid rise, level reaches pump “start” probe to start the pump. Pump will remain on until level is below “off” probe. The “off” probe senses air or oil and turns the pump off so the oil layer will not be pumped out of the tank. If the level reaches alarm probe and mechanical float, the system will differentiate between water and oil and activate the remote alarm.

    1/2 HP Elevator Sump Pump System with LittleGiant 10EC Sump Pump Downloadable Documents

    FileName
    10ec_series_spec_sheetViewDownload
    7410_OilAlert_InstallationViewDownload
    7410_OilAlert_SpecificationsViewDownload
