Alderon Go2 Totalizer WiFi Enabled Timed or Demand Dose Duplex Control Panel (120/230V, 0-20 FLA)

Print

The Alderon Go2 Totalizer WiFi Enabled duplex control panel is designed to control and monitor a two pump system using either demand dose or timed dose functionality. Includes pump circuitry, high water alarm, and 3 mechanical float switches the can be programmed to your desired functionality.

The Alderon Go2 Totalizer panels feature a revolutionary menu system that enables maximum field configuration and statistics tracking. A convenient setup wizard is included in the menu to get the panel configured to your desired functionality in a few simple steps.

This panel is Vizzylink WiFi enabled for remote monitoring and receiving text and email alerts for system conditions.

Made In USANEMA 4XUL Listed

Coming Soon!

$1275.00MSRP: $1845.00

Item #:2012794

Manufacturer: Alderon

THIS ITEM WILL BE AVAILABLE SOON! CALL (877)-925-5132 TO BE NOTIFIED WHEN THIS ITEM IS AVAILABLE FOR PURCHASE.

GO2 TOTALIZER DUPLEX SPECIFICATIONS

  • Model: GO2T1D230H20-CT6V1-3AGHPR20
  • Controls Duplex Pumps at 120/230VAC, Single Phase, 0-20 FLA
  • Single Power Input that splits to Pump Power for Two Pumps and Control Power within the panel
  • (2) 25 Amp Pump Circuit Breakers, 10 Amp Control Circuit Breaker
  • Includes (3) Mechanical Floats w/ 20ft Cords
  • Automatic Alternating Relay switches lead pump each cycle
  • Vizzylink WiFi Enabled for Remote Monitoring
  • Programmable for Time Dosing or Demand Dosing
  • Advanced Menu System to Maximum Field Configuration Options
  • Simple Setup Wizard in the Menu, Configures in minutes!
  • High decibel alarm buzzer (100 dB)
  • Pump Hand/Off/Auto Toggle with Indicator Light for Each Pump
  • Lever style Terminal Blocks - Screwdriver-less installation
  • Conformal Coated Circuit Boards for Reliable Thermal and Moisture Protection
  • Built-In Printed Circuit Board Surge Protection
  • Double-Pole Hybrid Solid State Relay (1,000,000 cycle rating)
  • Automatic Resettable Alarm and Control Fuses
  • Includes Auxiliary Dry Contacts (Normally Open/Normally Closed activated for any Alarm or Power Loss
  • Pad-Lockable NEMA 4X Enclosure, UL 508A Listed
  • Dimensions: 12.00'' W x 10.00'' T x 4.00'' D
  • Three Year Manufacturer's Warranty

VIZZYLINK WIFI ENABLED

  • Remote monitoring through Vizzy Portal
  • Must be installed within range of internet connected WiFi
  • Receive Text and Email Alerts for System Conditions
  • Can be accessed via Web Browser
  • Mobile App Available on both Android and Apple IOS Devices

GO2 TOTALIZER ADVANCED FEATURES

  • Easily Change Configurations
    • Demand Dosing
    • Timed Dosing (Low Alarm/Redundant Off, Timer Enable, Peak Timer, High Alarm)
  • Digital Amp Meter
    • Display real-time pump running amps
    • Track amperage statistics: High, Low, Min/Max/Average
    • Used for Pump and Relay failure detection
  • Advanced Pump Station Statistic Tracking
    • Pump Elapsed Time
    • Min/Max/Avg Pump Run Times
    • Pump Cycle Counter
    • Total Gallons Pumped
    • High Level Stats
    • Many More
  • Multi-Color Super Bright LED Light Strip
    • Green = Normal
    • Red = Alarm
    • Blue = Pump Run
    • Red/Yell = Sensor Error
    • Many More
  • Multiple Sensor Options
    • Field accepts up to 4 Float Inputs (Off, Lead On, Lag On, Alarm)

Alderon Go2 WiFi Enabled Duplex Time or Demand Dose Control Panel Videos

Alderon Go2 Totalizer Menu Overview

Alderon Go2 WiFi Enabled Duplex Time or Demand Dose Control Panel Downloadable Documents

FileName
GO2T1DXXX-CT6 InstallationViewDownload
GO2T1DXXX-CT6 SpecificationViewDownload
