Alderon GOOP Grease Trap & Oil Separator Alarm System

The GOOP alarm is a universal alarm designed for detecting grease or oil within water-oil/grease separator tanks. Two suspended grease/water conductivity probes are installed in the grease trap or oil separator. When grease or oil surrounds the tip of a suspension probe, the alarm is activated.

When the alarm is activated, the beacon flashes red, and the buzzer and alarm dry contacts are activated. The buzzer can be silenced by activating the test/silence toggle switch. The alarm automatically resets when the alarm condition is cleared, and the beacon turns green, indicating that the system is operating normally.

Ships In 5-7 Business Days

$715.00MSRP: $1076.67

Item #:GA240+2PS20

Manufacturer: Alderon

Product Documents

GOOP GA240 Installation

GOOP GA240 Specification

GOOP GREASE / OIL INTERCEPTOR ALARM FEATURES

Model: GA240+2PS20
Operates on 120 or 230VAC Incoming Power Supply
Includes (2) Probe Sensors for Reference and Alarm
A third probe sensor can be added for a secondary alarm
Status LEDs show which sensors are activated
Alarm Beacon with Vibrant Multi-Color LEDs
- Green = Normal
- Red Flashing = Sensor Alarm
Built-in Printed Circuit Board Protection (conformal coated)
Auxiliary Dry Contacts Included
- Alarm 1 - Grease or Oil
- Alarm 2 - Grease or Oil
Test / Configure Button to Activate Test Routine, Clear Alarms, Enable Settings
Exterior Test / Silence Switch to Test Alarm or Silence Buzzer during Alarm
Nema 4X Enclosure, Indoor or Outdoor, Pad-Lockable
Dimensions: 8'' x 6'' x 4''

GOOP ALARM APPLICATIONS

The Alderon Industries GOOP Alarm is a universal grease and oil detection alarm specifically designed for grease traps, oil/water separators, and interceptor tanks.

Feature	Description
Purpose	Detects grease or oil buildup in FOG (fats, oils, grease) interceptors and oil/water separators
Applications	Commercial kitchens, restaurants, food processing, car washes, industrial facilities
Tank Sizes	Works in small under-sink traps and large 500+ gallon interceptors
Detection Methods	Suspended conductivity probes
