• 300 Gallon Duplex Fiberglass Pump Station with (2) 4/10 HP Sewage Ejector Pumps and Alternating Control Panel - Part Number 300FPT-410SDUP

300 Gallon Duplex Fiberglass Pump Station with (2) 4/10 HP Sewage Ejector Pumps and Alternating Control Panel

Print

57" Diameter x 71" Tall Basin • True Duplex Redundancy • 20 ft Max Head • Up to 100 GPM • Pre-Assembled Sewage Lift Station with Alarm

This 300-gallon duplex sewage ejector pump station is a reliable, pre-assembled solution designed for residential raw sewage and wastewater applications requiring redundancy. Equipped with two 4/10 HP Little Giant sewage ejector pumps and an automatic alternating control panel, the system provides backup protection and even pump wear — ensuring continuous operation even if one pump needs service. Ideal for homes with basements or low-lying plumbing that must pump sewage to a septic tank or city sewer main where gravity flow is not possible.

Built To Order Within 1-2 Business Days

$4495.00MSRP: $4799.00

Item #:300FPT-410SDUP

Manufacturer: Septic Solutions

THIS ITEM SHIPS LTL FREIGHT. APPROXIMATE TRANSIT TIME IS 2-5 BUSINESS DAYS. PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

FEATURES & BENEFITS

  • True Duplex Redundancy — Two independent 4/10 HP ejector pumps with automatic alternation for balanced operation and built-in backup.
  • Heavy-Duty Fiberglass Basin — 300-gallon capacity (57" diameter x 71" tall) engineered for direct burial with excellent corrosion resistance.
  • Little Giant Sewage Ejector Pumps — Handle up to 2" solids, perfect for raw sewage containing toilet paper, human waste, and light debris.
  • Alternating Control Panel — Features automatic alternation, high-water alarm, pump run indicators, and HOA switches.
  • Pre-Assembled & Ready to Install — Includes pumps, floats, discharge piping, check valves, and 24" access cover.
  • Solid Performance — Each pump delivers up to 100 GPM with a maximum head of 20 ft.

TECHNICAL SPECIFICATIONS

300-Gallon Fiberglass Tank

  • Dimensions: 57" Diameter x 71" Tall
  • Heavy-duty fiberglass for direct burial
  • 24" Polylok access cover (risers available)
  • 4" inlet with grommet
  • 2" SCH 40 discharge pipe sealed with grommet
  • Cord seals for power and control wiring

Little Giant 4/10 HP Sewage Ejector Pumps (Qty: 2) — Model 9SC-CIA-RF

  • 4/10 HP, 115V, 8.0A, 60 Hz, single phase
  • Performance: 80 GPM @ 10 ft head • Max 100 GPM • Shut-off: 20 ft
  • 2" NPT vertical female discharge
  • Handles 2" solids
  • Includes 20 ft mechanical float switch
  • 3-Year Manufacturer Warranty

SPI #50A506 Duplex Control Panel

  • 120/240VAC single phase, 0-20 FLA
  • Automatic alternating relay
  • (3) mechanical float switches with 20 ft cords
  • 360° red alarm beacon + 100 dB audible buzzer
  • Pump run indicators, HOA switches, Alarm Test/Mute
  • NEMA 4X weatherproof enclosure, UL 508A listed
  • 2-Year Limited Warranty

Important Note: Sewage ejector pumps are designed for pumping raw sewage into a septic tank or gravity sewer main. For pumping to a pressurized force main, use grinder pumps instead.

APPLICATIONS

  • Residential homes with basements or multiple below-grade fixtures
  • Pumping sewage from the house to a septic tank
  • Retrofitting properties to connect to city sewer
  • New construction where gravity drainage is unavailable
  • Light commercial buildings requiring reliable backup
This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.

    300 Gallon Duplex Pump Station with (2) 4/10 HP Sewage Pumps Downloadable Documents

    FileName
    300FPT-410SDUP_Spec1ViewDownload
    300FPT-410SDUP_Spec2ViewDownload
    300FPT-410SDUP_Spec3ViewDownload
    Pump-Station-Backfill-InstructionsViewDownload
