200 Gallon Simplex Fiberglass Pump Station with 1/2 HP Effluent Pump
Print48" Diameter x 69" Tall Basin • 37 ft Max Head • Up to 70 GPM • Pre-Assembled Effluent Lift Station
This 200-gallon simplex effluent pump station is a complete, ready-to-install solution designed for residential applications requiring reliable pumping of treated effluent with minimal solids. It features a durable fiberglass basin paired with a Liberty 1/2 HP effluent pump, making it ideal for pumping from a septic tank or aerobic treatment system to a leach field or secondary treatment system where gravity flow is not possible.
Built To Order Within 1-2 Business Days
Item #:200FPT-283
Manufacturer: Septic Solutions
FEATURES & BENEFITS
- Pre-Assembled & Ready to Install — Arrives fully assembled with pump, basin, access cover, discharge piping, and mechanical float switch for fast installation.
- Heavy-Duty Fiberglass Construction — 200-gallon tank (48" diameter x 69" tall) engineered for direct burial with excellent corrosion resistance and structural strength.
- Liberty 1/2 HP Effluent Pump — Designed specifically for pumping treated effluent with minimal solids using a vortex impeller.
- Solid Performance — Delivers up to 70 GPM with a maximum head of 37 ft.
- Easy Access — Includes a 24" diameter Polylok access cover; optional risers available to bring service to grade.
- Reliable Automatic Operation — Includes a wide-angle mechanical float switch with piggyback plug.
TECHNICAL SPECIFICATIONS
200-Gallon Fiberglass Tank
- Dimensions: 48" Diameter x 69" Tall
- Heavy-duty fiberglass for direct burial
- 24" Polylok access cover
- 4" inlet with grommet
- 2" SCH 40 discharge pipe sealed with grommet
- Cord seals for power and float switch
Liberty 1/2 HP Effluent Pump (Model 283)
- 1/2 HP, 115V, 8.0A, 60 Hz, single phase
- Performance: 50 GPM @ 15 ft head • Max 70 GPM • Shut-off: 37 ft
- 1-1/2" NPT vertical female discharge
- Handles 3/4" solids
- Vortex style impeller
- Heavy-duty cast iron construction with one-piece unibody casting
- Includes quick-disconnect 10' power cord with plug
- Includes 10' wide-angle mechanical float switch with piggyback plug
- Dimensions: 9.5" L x 6.4" W x 13.2" H
- 3-Year Manufacturer Warranty
APPLICATIONS
- Pumping treated effluent from septic tanks or aerobic treatment systems
- Dosing to leach fields or secondary treatment systems
- Homes with basements or below-grade plumbing
- New construction where gravity flow is not possible
- Retrofitting existing properties
WHAT'S INCLUDED
- 200-gallon fiberglass pump basin
- Liberty 1/2 HP Model 283 effluent pump
- Mechanical float switch
- 24" Polylok access cover
- Pre-installed discharge piping and seals
- All necessary grommets and hardware
RELATED ITEMS SOLD SEPARATELY
These items are considered optional but are often added to our pump stations:
- Alarm and/or Control Panel (Choose Only One of These Options):
- Other Optional Items:
This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.
