300 Gallon Simplex Fiberglass Pump Station with 3/4 HP Sewage Ejector Pump

FEATURES & BENEFITS

• Pre-Assembled & Ready to Install — Arrives fully assembled with pump, basin, access cover, discharge piping, and mechanical float switch for fast installation.
• Heavy-Duty Fiberglass Construction — 300-gallon tank (57" diameter x 71" tall) engineered for direct burial with excellent corrosion resistance and structural strength.
• Powerful 3/4 HP Liberty Sewage Ejector Pump — Handles up to 2" solids with strong flow rates, ideal for medium-to-heavy residential sewage demands.
• High Performance — Delivers up to 160 GPM with a maximum head of 29–30 ft.
• Easy Access — Includes a 24" diameter Polylok access cover; optional risers available to bring service to grade.
• Reliable Automatic Operation — Includes a wide-angle mechanical float switch with piggyback plug.

TECHNICAL SPECIFICATIONS

300-Gallon Fiberglass Tank

• Dimensions: 57" Diameter x 71" Tall
• Heavy-duty fiberglass for direct burial
• 24" Polylok access cover
• 4" inlet with grommet
• 2" SCH 40 discharge pipe sealed with grommet
• Cord seals for power and float switch

Liberty 3/4 HP Sewage Ejector Pump (Model LE71A)

• 3/4 HP, 115V, 12.0A, 60 Hz, single phase
• Performance: 100 GPM @ 15 ft head • Max 160 GPM • Shut-off: 29–30 ft
• 2" NPT vertical female discharge
• Handles 2" solids
• 2-vane cast iron impeller
• Heavy-duty cast iron construction
• Includes 10 ft quick-disconnect power cord with plug
• Includes 10 ft wide-angle mechanical float switch with piggyback plug
• Dimensions: 12.5" L x 9.0" W x 15.3" H
• 3-Year Manufacturer Warranty

Important Note: Sewage ejector pumps are designed for pumping raw sewage into a septic tank or gravity sewer main. For pumping to a pressurized force main, use grinder pumps instead.

APPLICATIONS

• Homes with basements or below-grade bathrooms
• Pumping sewage from the house to a septic tank
• Retrofitting existing properties to connect to city sewer
• New construction on lots without gravity drainage
• Medium-duty residential wastewater applications

WHAT'S INCLUDED

• 300-gallon fiberglass pump basin
• Liberty 3/4 HP sewage ejector pump (LE71A)
• Wide-angle mechanical float switch
• 24" Polylok access cover
• Pre-installed discharge piping and seals
• All necessary grommets and hardware

RELATED ITEMS SOLD SEPARATELY

These items are considered optional but are often added to our pump stations:

• Alarm and/or Control Panel (Choose Only One of These Options):
  • Observer 500 High Water Alarm
  • Alderon Pump Guard Economy Simplex Control Panel
  • Legacy Controls LE-4003 Simplex Control Panel
• Other Optional Items:
  • Check Valve
  • Additional Risers

This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.
