• 500 Gallon Simplex Fiberglass Pump Station with 1.0 HP Liberty Sewage Ejector Pump - Part Number 500FPT-LE102

500 Gallon Simplex Fiberglass Pump Station with 1.0 HP Liberty Sewage Ejector Pump

Print

70'' x 67'' BASIN, 1.0 HP SEWAGE PUMP, 39 FT OF HEAD, 190 GPM

This 500 gallon fiberglass pump station comes pre-assembled and ready to install with all of the components needed to install a direct burial in-ground sewage lift station. This system is designed for raw sewage pumping applications. The typical application for this package is to pump sewage and wastewater from a household to the septic system or city sewer.

THIS ITEM SHIPS VIA LTL FREIGHT. PLEASE CALL 1-877-925-5132 TO GET A SHIPPING QUOTE OR PLACE AN ORDER.

Assembled In USA

Built To Order Within 1-2 Business Days

$3325.00MSRP: $3799.00

Item #:500FPT-LE102

Manufacturer: Septic Solutions

THIS ITEM SHIPS LTL FREIGHT.
PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

500 GALLON FIBERGLASS TANK

  • 70'' Diameter, 67'' Tall
  • Heavy Duty Fiberglass Designed For Direct Burial
  • 24'' Diameter Polylok Access Cover
  • Risers Available To Bring Access To Grade
  • 4'' Inlet Hole with Grommet
  • 2'' SCH 40 Discharge Pipe Sealed with Grommet
  • Cord Seals For Power and Float

LIBERTY 1.0 HP SEWAGE EJECTOR PUMP

  • Model LE102A
  • 1.0 HP, 230VAC, 8.0A, 60 Hz
  • 120 GPM @ 20ft of Head Pressure
  • Shut Off: 39ft, Max GPM: 190
  • 2'' NPT Vertical Female Discharge, 2'' Solids Handling
  • Heavy Duty Cast Iron Construction
  • 2-Vane Cast Iron Impeller
  • Includes Quick-Disconnect 10' Power Cord with Plug
  • Includes 10' Wide Angle Mechanical Float Switch with Piggyback Plug
  • Dimensions: 12.5'' L x 9.0'' W x 15.3'' T
  • Three Year Warranty

RELATED ITEMS SOLD SEPARATELY

These items are considered optional but are often added to our pump stations:

This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.

500 Gallon Pump Station with 1.0 HP Liberty Sewage Ejector Pump Downloadable Documents

FileName
500FiberglassTank_SpecViewDownload
LE102A_FeaturesViewDownload
LE102A_SpecificationsViewDownload
Pump-Station-Backfill-InstructionsViewDownload
