VertiMAC Sump Advisor Sump Pump Alarm and Control System with Vertical Pump Switch, Alarm Sensor, & Indoor Alarm Panel

Print
The VertiMAC™ Sump Advisor™ System is an innovative all-in-one system that includes the VertiMAC™ vertical sump pump on/off switch with a built in Sump Advisor™ sensor that connects to the alarm panel and indicates high water level as well as pump running status. The alarm panel has a 9-Volt battery backup connection and auxiliary contacts for high water alarm and pump run status to be connected to an autodialer, BAS system, or time meters and cycle counters.
CSAMade In USA

In Stock

$139.00MSRP: $185.00

Item #:2000547

Manufacturer: Alderon

VertiMAC™ Sump Advisor™ Features

  • Sump Advisor™ Indoor Alarm Panel
  • VertiMAC™ Vertical Float Switch with integrated Sump Advisor™ Sensor
  • 6' Alarm Panel Power Cord, 15' Sensor Cord
  • LED Lights to indicate Power Supply, High Water Alarm, and Pump Run Status
  • Alarm Test and Mute Button
  • Alarm Auxiliary Contacts - To Connect Auto Dialer or External Light/Buzzer
  • Pump Status Auxiliary Contacts - To Connect to ETM or Cycle Counter
  • Audible Buzzer: 103 dB @ 10 feet
  • 9 VDC Battery Backup (Battery Not Included)
  • CSA Approved in US and Canada
  • Alarm Panel Dimensions: 6'' T x 4'' W x 2'' D
  • Three Year Warranty

VertiMAC™ Sump Advisor™ Operation

When the water level rises, the float pushes the actuator rod upward which activates the mechanism inside the pump switch housing and turns the sump pump on. The Sump Advisor™ sensor will send a signal to the alarm panel, activating the green pump run LED indicator and the pump run auxiliary contacts. If the water level continues to rise activating the high level alarm float on the Sump Advisor™ sensor, the red high sump LED indicator, buzzer, and alarm auxiliary contacts on the alarm panel will activate. Pressing the alarm silence button will silence the buzzer. When the water level recedes, the float lowers the actuator rod downward which deactivates the mechanism inside the pump switch and turns the sump pump off. When the alarm condition is cleared, the system will automatically reset itself for the next alarm cycle. To adjust the pump on/off differential, slide the rubber grommet up or down the actuator rod for the desired pumping range.
