• Little Giant Model 6EC-CIA-RF 1/3 HP Submersible Effluent Pump - Part Number 506803

Little Giant Model 6EC-CIA-RF 1/3 HP Submersible Effluent Pump

Print

53 MAX GPM, 28 FT MAX HEAD, 1-1/2" DISCHARGE

The 6EC-CIA-RF effluent and sump pump from Little Giant is an energy-saving, high performance, fully submersible sump / effluent pump. Automatic operation is achieved with a piggyback wide angle remote float switch. The Little Giant 6EC series replaces the 6E and 6EN models.This item 506803 features a 30ft Power Cord and a cast iron body with a thermoplastic base.

Out of Stock

$275.00MSRP: $299.00

Item #:506803

Manufacturer: Little Giant

THIS PRODUCT IS CURRENTLY OUT OF STOCK
PLEASE CALL (877)-925-5132 FOR EXPECTED AVAILABILITY!

LITTLE GIANT 6EC SPECIFICATIONS

  • 1/3 HP, 115VAC, 5.0A, 60 Hz
  • 53 GPM @ 5 ft of Head Pressure
  • Shut Off: 28 ft, Max GPM: 53
  • 1-1/2'' NPT Vertical Female Discharge, 1/2' Solids Handling
  • 30ft Power Cord with Plug
  • Includes 30ft Mechanical Float Switch for Automatic Operation
  • Cast Iron Body with Thermoplastic Base
  • WHALE OF A DEAL - THREE YEAR WARRANTY!
  • Dimensions: 8.79 L x 8.48'' W x 10.90'' T

LITTLE GIANT 6EC APPLICATIONS

Our Sump and Effluent pumps are designed to handle wastewater with minimal solids or clear water. Most of our Effluent pumps have a 1-1/2’’ NPT discharge and some of the large units even have a 2’’ discharge. These pumps can handle smaller solids up to 3/4’’ in size. These units are normally used to pump discharge from a septic tank or an aerobic system to a drain field, secondary treatment system, or surface discharging point.

  • Effluent and Wastewater Removal
  • Residential Drainage
  • Non-Potable Water Removal
  • Non-Potable Water
  • Handles Up To 1/2'' Solids
  • Includes Float Switch For Automatic Operation
  • Heavy Duty Cast Iron Design

Little Giant 6EC-CIA-RF 1/3 HP Effluent Pump Downloadable Documents

FileName
506858_ManualViewDownload
506858_SpecViewDownload
