120 Gallon Simplex Fiberglass Pump Station with 1.0 HP Liberty Sewage Ejector Pump

28'' x 70'' BASIN, 1.0 HP SEWAGE PUMP, 53 FT OF HEAD, 200 GPM

This 120 gallon fiberglass pump station comes pre-assembled and ready to install with all of the components needed to install an in ground lift station. This Liberty LEH102 sewage ejector pump included in this system is designed for raw sewage pumping applications. The typical application for this package is to pump sewage and wastewater from a household to the septic system or city sewer.

THIS ITEM SHIPS LTL FREIGHT. PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

Built To Order Within 1-2 Business Days

$2325.00MSRP: $2799.00

Item #:120FPT-LEH102

Manufacturer: Septic Solutions

THIS ITEM SHIPS LTL FREIGHT. APPROXIMATE TRANSIT TIME IS 2-5 BUSINESS DAYS. PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

Product Documents

120FiberglassTank_Spec

LEH102A_Features

120 GALLON FIBERGLASS TANK

28'' Diameter, 70'' Tall
Heavy Duty Fiberglass Designed For Direct Burial
20'' Diameter Polylok Access Cover
Risers Available To Bring Access To Grade
4'' Inlet Hole with Grommet
2'' SCH 40 Discharge Pipe Sealed with Grommet
Cord Seals For Power and Float

LIBERTY 1.0HP SEWAGE PUMP

Model LEH102A
1.0 HP, 230VAC, 12.0A, 60 Hz
125 GPM @ 35ft of Head Pressure
15' MINIMUM HEAD REQUIREMENT
Shut Off: 53ft, Max GPM: 200
2'' NPT Vertical Female Discharge, 2'' Solids Handling
Heavy Duty Cast Iron Construction
2-Vane Cast Iron Impeller
Includes Quick-Disconnect 10' Power Cord with Plug
Includes 10' Wide Angle Mechanical Float Switch with Piggyback Plug
Dimensions: 12.6'' L x 9.0'' W x 15.3'' T
Three Year Warranty

RELATED ITEMS SOLD SEPARATELY

These items are considered optional but are often added to our pump stations:

This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.
