SPI Simplex Control Panel Model SSC12B (120V/230V, 0-20FLA)

Print

The SPI SSC12B Simplex Control Panel is designed to control and monitor a single submersible pump in a lift station. This sewage pump control panel includes pump circuitry, high water alarm, and 3 mechanical float switches for "OFF", "ON", and "ALARM" functions. The SSC12B is dual voltage and can run a submersible pump up to 20 amps at either 120 or 230 VAC.

Made In USANEMA 4XUL Listed

In Stock

$379.00MSRP: $595.00

Item #:50A006-C4

Manufacturer: SPI

SSC12B Simplex Control Panel Features

  • 120/230VAC, Single Phase, 0-20 FLA
  • (3) Mechanical Floats with 15ft cords and cable weights
  • 360 degree red alarm light
  • High decible alarm buzzer (85 dB)
  • Pump run indicator light
  • Pump Hand/Off/Auto heavy duty toggle
  • Alarm On/Test heavy duty toggle
  • Alarm Silence heavy duty button
  • 2 pole definite purpose motor contactor (100,000 cycle rating)
  • Motor circuit breaker
  • Control circuit breaker
  • Stainless Steel lockable door latch
  • Color Coded Wiring, Field Wiring Terminal Strips
  • NEMA 4X Enclosure, UL508A Listing
  • Dimensions: 10.25'' x 12.125'' x 5.25''
  • Two Year Limited Warranty

SSC12B Control Panel Applications

The SPI SSC12B Simplex Pump Station control panel can operate a lift station with a single submersible pump. This dual voltage control panel can operate a submersible pump up to 20 FLA at either 120 or 230 VAC. The SPI SSC12B features separate circuits for the submersible pump and the control / alarm portion of the panel. This means the alarm will still be functional if the submersible pump trips its circuit breaker. This control panel also features the standard equipment in most simplex panels which include the pump HOA switch, run indicator light, alarm test and silence functions, and the audible and visual alarm system.

  • For Simplex Sewage Lift Stations
  • For Simplex Effluent Lift Stations
  • For Any Single Phase Submersible up to 20 FLA at 120V or 230V

SPI Model SSC12B Simplex Control Panel Downloadable Documents

FileName
50A006-C4_Connection-DiagramViewDownload
50A006-C4_SpecificationsViewDownload
