300 Gallon Pump Station with 1.0 HP Little Giant Residential Grinder Pump
Print57" Diameter x 71" Tall Basin • 53 ft Head • Up to 49 GPM • Ready-to-Install Simplex Grinder Lift Station
This complete 300-gallon simplex grinder pump station is a heavy-duty, pre-assembled solution designed for residential applications where raw sewage needs to be pumped uphill or over long distances to a main sewer line. It combines a durable fiberglass basin with a reliable Little Giant 1.0 HP grinder pump, making it ideal for homes with below-grade bathrooms, finished basements, or challenging site conditions.
Built To Order Within 1-2 Business Days
Item #:300FPT-10G
Manufacturer: Septic Solutions
FEATURES & BENEFITS
- Pre-Assembled & Ready to Install — Arrives fully assembled with pump, basin, access cover, discharge piping, and float switch for fast, professional installation.
- Heavy-Duty Fiberglass Construction — The 300-gallon tank (57" diameter x 71" tall) is engineered for direct burial and offers excellent corrosion resistance and structural strength.
- Powerful Little Giant Grinder Pump — Handles tough solids (feminine products, wipes, rags, etc.) by grinding them into a fine slurry that can be pumped through smaller-diameter lines without clogging.
- High Performance — Delivers up to 49 GPM and a maximum head of 53 ft, providing reliable lift for demanding applications.
- Easy Access — Includes a 24" diameter Polylok access cover with optional risers to bring service to grade level.
- Quality & Reliability — Built with quality components backed by a 3-year warranty on the pump.
TECHNICAL SPECIFICATIONS
300-Gallon Fiberglass Tank
- Dimensions: 57" Diameter x 71" Tall
- Heavy-duty fiberglass for direct burial
- 24" Polylok access cover
- 4" inlet with grommet
- 2" SCH 40 discharge pipe (sealed with grommet)
- Cord seals for power and float switch
Little Giant 1.0 HP Grinder Pump (Model 16G-F151-20)
- 1.0 HP, 115V, 12.5A, 60 Hz
- Performance: 37 GPM @ 25 ft head • Max 49 GPM • Shut-off: 53 ft
- 2" NPT vertical female discharge
- Heavy-duty cast iron construction
- Includes 20 ft power cord with plug
- Includes 20 ft wide-angle mechanical float switch with piggyback plug
- Shreds difficult solids effectively
- Dimensions: 11.33" L x 10.03" W x 18.41" H
- 3-Year Manufacturer Warranty
Note: Grinder pumps are designed for pumping to a city sewer main or force main. They are not recommended for pumping directly into a septic tank (use a sewage ejector pump for that application).
APPLICATIONS
- Homes with basements or low-lying plumbing
- Retrofitting existing properties to connect to city sewer
- New construction where gravity flow is not possible
- Challenging lots requiring high head pressure
WHAT'S INCLUDED
- 300-gallon fiberglass pump basin
- Little Giant 1.0 HP grinder pump
- Wide-angle mechanical float switch
- 24" Polylok access cover
- Pre-installed discharge piping and seals
- All necessary grommets and hardware
RELATED ITEMS SOLD SEPARATELY
These items are considered optional but are often added to our pump stations:
- Alarm and/or Control Panel (Choose Only One of These Options):
- Other Optional Items:
This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.
