Double M-Navigator Dual Mechanical Pump Float Switch with 15' Cord, 120VAC Piggyback Plug

Print

This mechanically activated dual float pump switch has normally open contacts designed for emptying applications. The switch is normally open and is activated to "ON" in the raised position. Dual float switches allow for a more flexible pumping range than a single float switch.

A Built-In Relay Allows these floats to work in conjunction with one another without the need for a control panel.

RUCSA

In Stock

$168.00MSRP: $203.00

Item #:20A505

Manufacturer: SPI

Ships Today
with FREE SHIPPING

Order in the next: -- hr --min --sec

Ship Date Mon, Nov 24

Delivery: 1-4 Business Days

  • Normally Open Contacts for Emptying Applications
  • Activates To ON In The Raised Position
  • Designed For Use In Sewage and Wastewater Applications
  • Controls Pumps Up To 15 Amps At 120VAC
  • Piggy-Back Plug For Easy Installation
  • Custom Cord Lengths Available, Call 1-877-925-5132
  • Dual Mechanical Pump Switches
  • 15' Cord with Piggyback Plug
  • 15 Amp, 14/3 SJOW Wire, 120V
  • Controls Pumps Up To 1 HP @ 120V and 2 HP @ 240V
  • Adjustable Pumping Range of 2 to 54 Inches
  • SST Pipe Mount Assembly Included
  • UL Listed, CSA Listed, Heavy Duty Contacts
