Gast 1023 Rotary Vane Septic Air Pump

Print

The Gast 1023-101Q Rotary Vane Septic Air Pump is a durable and high-performance aerator designed for aerobic septic systems and pond aeration. Known for its robust construction and reliable operation, the 1023 is a trusted choice for systems requiring high back pressure and long-term service. This unit can be wired at 230V or 115V, but comes pre-wired for high voltage.

In Stock

$1005.00MSRP: $1200.00

Item #:1023

Manufacturer: Gast

Choose Your Voltage:

External Filter Assembly:

Gast 1023 Rotary Vane Specifications

  • Gast Model 1023-101Q-SG608X
  • 10.0 cfm Open Flow
  • 10.0 psi Maximum Continuous Pressure
  • 3/8'' Female Threaded Outlet
  • 3/4 HP, 120/230VAC, 60 Hz, 9.6/4.8A
  • Comes Pre-Wired for 230VAC Operation - Can Be Re-Wired for 115VAC in the Field
  • 1 Phase, 1725 RPM, 1.00SF
  • Dimensions: 16.20'' L x 6.50'' W x 8.88'' H
  • Includes All Filters and Mounting Feet
  • Condition:NEW
  • Replacement Parts Available
  • One Year Manufacturer's Warranty

Gast 1023 Rotary Vane Features

The Gast 1023 Rotary Vane Septic Air Pump is engineered to deliver consistent airflow with minimal maintenance, making it ideal for demanding applications. Its sturdy design and oil-less operation ensure clean, efficient performance for years. Key features include:

  • Exceptional Durability: Built with a tough cast iron housing and sealed bearings, it lasts 8-10 years with proper care, featuring nickel-plated rotors and a vane coating that minimizes wear.
  • High Back Pressure Handling: Operates at up to 10 PSI, four times more than linear diaphragm pumps, perfect for systems with clogged diffusers or high resistance.
  • Oil-Less Design: Provides clean, contaminant-free air without lubrication, ensuring safe wastewater treatment and pond aeration.
  • Low Maintenance: Readily available repair parts like vane kits and filters simplify upkeep, keeping downtime to a minimum.
  • Versatile Power: Dual voltage (115V or 230V, pre-wired for 120V) accommodates various system setups.

Gast 1023 Rotary Vane Applications

The Gast 1023 is vital for aerobic septic systems, supplying oxygen to support waste-breaking bacteria and producing clean, odorless effluent. Its high-pressure capability ensures reliable performance even in challenging conditions, preventing system failure. For pond aeration, it oxygenates water up to 18 feet deep, promoting a healthy aquatic environment. Without proper aeration, septic systems may turn anaerobic, leading to untreated effluent, while ponds risk algae growth and fish loss.

  • Replaces older Gast 1023 and 0823 models
  • Dual Voltage (Pre-Wired for 230VAC)
  • Septic Air Pump
  • Fits Many 1000 and 1500 GPD Aerobic Systems
  • Septic Tank Aeration
  • Pond and Water Garden Aeration

Gast 1023 Rotary Vane Aerator Downloadable Documents

FileName
1023_BrochureViewDownload
1023_SpecViewDownload
