Hiblow HP-80 Linear Septic Air Pump with Attached Alarm

Hiblow HP-80-015A Specifications

• 4.2 cfm (cubic feet per minute) Maximum Air Flow (@ 0 PSI)
• 80 LPM (Liters Per Minute) @ 2.13 PSI
• 3.6 PSI Maximum Continuous Operating Pressure
• 120 VAC, 60 Hz, 1.6A, 71 Watts
• 36 dBA Measured @ 1 Meter
• Includes Attached Alarm To Signal Air Pump Failure
• Alarm Includes Run / Test / Mute Switch
• Dimensions: 9.3'' L x 7.1'' W x 7.8'' H

• Condition: NEW

• Includes Rubber 90 with Hose Clamps

• Replaces HP-80-013A, Thomas 5078S and 5080S, Secoh EL-80-15, Medo LA-80B, and other 80 LPM Linear Air Pumps
• Fits Many 500 and 600 GPD Aerobic Treatment Systems (Sizing is Determinded By Brand of Aerobic System)
• WHALE OF A DEAL - EXTENDED TWO YEAR WARRANTY!
  (The Standard Manufacturer's Warranty is one year and Septic Solutions' warranties this unit in full for an additional year)

Hiblow HP-80-015A Applications

The Hiblow HP-80 linear septic air pump is commonly used on many 500 GPD and 600 GPD rated NSF Class 1 Standard 40 aerobic treatment systems (ATUs). The Hiblow linear diaphragm septic air pumps are widely regarded as the highest quality and longest lasting septic air pumps available on the market. They are extremely quiet and very energy efficient. The Hiblow HP-80 can be used for septic tank aeration as well as an aerator for small ponds.

AEROBIC SYSTEM COMPATIBILITY

The Hiblow HP-80 septic air pump is compatible for use on many 500 & 600 GPD (Gallons Per Day) rated aerobic treatment units, including but not limited to the following systems:

THE LIFELINE TO YOUR AEROBIC SEPTIC SYSTEM!

The Hiblow HP-80 with Alarm serves as the vital core of your aerobic septic system, delivering oxygen to nourish waste-consuming aerobic bacteria while stirring solids to facilitate efficient decomposition. The built-in alarm promptly notifies you of any malfunctions, preventing the system from reverting to an anaerobic state within approximately two weeks, which could lead to effluent resembling raw sewage. Accurate sizing is essential, and this pump is specifically designed for 500-600 GPD systems to ensure peak performance.

Additionally, the air pump generates movement within the tank, breaking down large solids into fine particles, simplifying the process for bacteria to adhere to and break down waste effectively.

Should the air pump fail in your aerobic system, it may take about two weeks for the system to shift back to an anaerobic condition. Unlike conventional anaerobic septic systems, which include a secondary treatment stage, an aerobic system lacks this backup. Once it turns anaerobic, the effluent will no longer be clear and odorless but will resemble raw sewage. Discharging such effluent into a ditch, lake, pond, or onto your lawn poses significant environmental and health risks. This underscores the critical need to keep your air pump operational to maintain system integrity.

SEPTIC AIR PUMP SIZE DOES MATTER!

The other misconception is that the air pump just puts air in the water, so it doesn’t really matter which size is used. Nothing could be further from the truth. Air pump sizing is actually very important to the operation of your system, and not every system will use the same size air pump. If you have been our website, then you already know there are many different types and sizes. The air pump size is normally determined by the volume capacity of the tank, the style of air diffusers in the tank, and how many GPD (Gallons Per Day) the system is designed to treat.

Our sales team can make sure you get the right size pump if you are unsure about this aspect of buying a new one. In most cases we only need either the model number of the pump you are replacing, or the brand of your aerobic system and the GPD that it is rated to treat. Again, size does matter and it is very important that you get the correct air pump for your system.
