• Little Giant Model 9EC-CIA-RF 4/10 HP Submersible Effluent Pump - Part Number 509801

Little Giant Model 9EC-CIA-RF 4/10 HP Submersible Effluent Pump

Print

70 MAX GPM, 40 FT MAX HEAD, 1-1/2" DISCHARGE

Submersible effluent pumps are designed to handle treated wastewater from a septic tank or an aerobic system. The Little Giant 9EC series provides high efficiency and long term dependability.

In Stock

$295.00MSRP: $399.00

Item #:509801

Manufacturer: Little Giant

LITTLE GIANT 9EC SPECIFICATIONS

  • 4/10 HP, 115VAC, 7.5 A, 60 Hz
  • 70 GPM @ 5 ft of Head Pressure
  • Shut Off: 40 ft, Max GPM: 70
  • 1-1/2'' NPT Vertical Female Discharge, 3/4'' Solids Handling
  • Includes 20ft Mechanical Float Switch for Automatic Operation
  • Three Year Warranty
  • Dimensions: 8.9'' L x 8.4'' W x 11.0'' T

LITTLE GIANT 9EC APPLICATIONS

Our Sump and Effluent pumps are designed to handle wastewater with minimal solids or clear water. Most of our Effluent pumps have a 1-1/2’’ NPT discharge and some of the large units even have a 2’’ discharge. These pumps can handle smaller solids up to 3/4’’ in size. These units are normally used to pump discharge from a septic tank or an aerobic system to a drain field, secondary treatment system, or surface discharging point.

  • Effluent and Wastewater Removal
  • Residential Drainage
  • Non-Potable Water Removal
  • Non-Potable Water
  • Handles Up To 3/4'' Solids
  • Includes Float Switch For Automatic Operation
  • Heavy Duty Cast Iron Design

Little Giant 9EC-CIA-RF 4/10 HP Effluent Pump Downloadable Documents

FileName
509801_9ec_series_spec_sheetViewDownload
