• 500 Gallon Pump Station with 2.0 HP Little Giant Sewage Grinder Pump - Part Number 500FPT-20G

500 Gallon Pump Station with 2.0 HP Little Giant Sewage Grinder Pump

Print

70'' x 67'' BASIN, 2.0 HP GRINDER PUMP, 130 FT OF HEAD, 32 GPM

This 500 gallon fiberglass pump station comes pre-assembled and ready to install with all of the components needed to install a direct burial in-ground sewage lift station. This system is designed for raw sewage pumping applications. The typical application for this package is to pump sewage and wastewater from a residential or commercial property to the city sewer.

THIS ITEM SHIPS VIA LTL FREIGHT. PLEASE CALL 1-877-925-5132 TO GET A SHIPPING QUOTE OR PLACE AN ORDER.

Built To Order Within 1-2 Business Days

$4765.00MSRP: $5199.00

Item #:500FPT-20G

Manufacturer: Septic Solutions

THIS ITEM SHIPS LTL FREIGHT.
PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

500 GALLON FIBERGLASS TANK

  • 70'' Diameter, 67'' Tall
  • Heavy Duty Fiberglass Designed For Direct Burial
  • 24'' Diameter Polylok Access Cover
  • Risers Available To Bring Access To Grade
  • 4'' Inlet Hole with Grommet
  • 1-1/2'' SCH 40 Discharge Pipe Sealed with Grommet
  • Cord Seals For Power and Float

LITTLE GIANT 2.0 HP SEWAGE GRINDER PUMP

  • 2.0 HP, 230VAC, 13.9A, 60Hz, 1 Phase, 3450 RPM
  • 30 GPM @ 60ft of Head Pressure
  • Shut Off: 130ft, Max GPM: 32
  • Includes Mechanical Float Swtich for Automatic Operation
  • Internal Capacitors - No Control Panel Required
  • Stainless Steel Leg Kit Included
  • UL/CSA Listed
  • Two Year Warranty
  • Dimensions: 11.50"L x 9.63"W x 21.56"H

NOTE: It is not recommended to use a sewage grinder pump to pump into a septic system. A sewage ejector pump is best for this application.

RELATED ITEMS SOLD SEPARATELY

These items are considered optional but are often added to our pump stations:

This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.

500 Gallon Pump Station with 2.0 HP Little Giant Grinder Pump Downloadable Documents

FileName
500FPT_SpecViewDownload
520875_SpecViewDownload
Pump-Station-Backfill-InstructionsViewDownload
