  • Franklin Electric Bottom-Suction High Head Effluent Pump - 1/2 HP, 20 GPM - Part Number 90302005

Franklin Electric Bottom-Suction High Head Effluent Pump - 1/2 HP, 20 GPM

Print

The Franklin Electric C1 Series Bottom-Suction high head effluent pump is a robust submersible pump designed for high-pressure wastewater applications. With a 1/2 HP motor and 20 GPM flow rate, this pump is ideal for spray irrigation, drip irrigation, and mound systems following aerobic treatment.

This submersible pump is bottom-suction, meaning it intakes water from the bottom of the unit.The Franklin Electric C1 series is a compatible replacement for the Sta-Rite Dominator and Clearstream P20D.

In Stock

$350.00MSRP: $389.00

Item #:90302005

Manufacturer: Franklin Electric

PumpSaver™ Filter Screen:

Float Switch Options:

Franklin Electric C1 Specifications

  • Franklin Electric Model 20C1-05P4-2W115
  • 20 Gallons Per Minute, 150 Feet of Head (65 psi)
  • 1/2 HP, 115V, 60Hz, 10.0A, 1 Ph, 3450 RPM
  • 1-1/4 NPT Female Threaded Discharge
  • Bottom Suction with Stainless Steel Screen
  • 5'' Removable Base For Secure and Reliable Mounting
  • Heavy Duty 2-Wire With Ground Cord Attached (10 Feet)
  • Built-In Check Valve
  • Dimensions: 26'' L x 3.75'' Diameter
  • Condition: Brand New!
  • WHALE OF A DEAL - EXTENDED TWO YEAR WARRANTY!
    (The Standard Manufacturer's Warranty is one year and Septic Solutions' warranties this unit in full for an additional year)

Franklin Electric C1 Features

The Franklin Electric C1 Series Bottom-Suction High Head Effluent Pump is engineered for durability and efficiency, making it a reliable choice for transferring clean, treated effluent. Its bottom-suction design maximizes fluid drawdown, though it requires careful installation to avoid clogging. Key features include:

  • High-Head Performance: Delivers 20 GPM at 150 ft of head (65 PSI), perfect for spray irrigation, underground drip systems, or mound systems.
  • Bottom-Suction Design: Intakes water from the bottom, allowing maximum drawdown but requiring elevation (e.g., PVC spacer) to prevent debris intake in aerobic systems.
  • Durable Construction: Features a stainless steel screen, thermoplastic discharge, and a robust motor housing, built for continuous duty with a lifespan of up to 15 years.
  • Clean Effluent Handling: Designed for treated effluent with no solids, typically installed after an aerobic treatment system.
  • Easy Installation: Includes a 10 ft, 600V SJOOW-rated power cable with pre-stripped leads and a removable 5-inch base for secure mounting.
  • Interchangeable: Compatible with Sta-Rite Dominator and Clearstream P20D models.

Franklin Electric C1 Applications

The Franklin C1 Series High Head Effluent Pumps are most commonly used in high pressure water removal applications such as spray irrigation or underground drip irrigation. These submersible pumps can handle only clean, treated effluent with no solids. They are normally installed after an Aerobic Treatment System.

  • Spray Irrigation
  • Underground Drip Systems
  • Mound Systems
  • High Pressure or Long Distance Pumping
  • Can Only Handle Clear Water or Treated Wastewater
  • Commonly Used After Aerobic Septic Systems
  • Replaces the Sta-Rite Dominator 20DOM05121
  • Replaces the Clearstream P20D

The Franklin Electric C1 Series High Head Effluent pump is a bottom suction unit. This means the pump will intake water at the bottom of the unit. Although this is a more risky setup in an aerobic system design, some systems use the bottom suction units and elevate them off of the bottom of the tank using a PVC pipe spacer. If this is the kind of set up you are replacing, the Franklin Electric C1 is your best choice.
