Franklin Electric FPS Model IGP-A231-20 2.0 HP Submersible Sewage Grinder Pump

Print

32 MAX GPM, 130 FT MAX HEAD, 1-1/4" DISCHARGE

The Franklin FPS IGP series features a heavy-duty, two capacitor motor and a unique patented cutter design. This centrifugal pump is ideal for light commercial or residential applications. With higher head pressures than other units on the market, the IGP Series performs at the highest of standards.

The Franklin FPS IGP-A231 is the direct replacement for the Little Giant GP-A231.

In Stock

$1450.00MSRP: $1795.00

Item #:515861

Manufacturer: Franklin Electric

FRANKLIN ELECTRIC FPS IGP-A231 SPECIFICATIONS

  • 2.0 HP, 230VAC, 13.9A, 60Hz, 1 Phase, 3450 RPM
  • 30 GPM @ 60ft of Head Pressure
  • Shut Off: 130ft, Max GPM: 32
  • 1-1/4'' NPT Vertical Female Discharge
  • Includes Mechanical Float Swtich for Automatic Operation
  • Internal Capacitors - No Control Panel Required
  • Stainless Steel Leg Kit Included
  • UL/CSA Listed
  • Two Year Warranty
  • Dimensions: 11.50"L x 9.63"W x 21.56"H

FRANKLIN ELECTRIC FPS IGP-A231 APPLICATIONS

Sewage Grinder pumps are also designed to handle raw sewage pumping jobs, just like the Sewage Ejector pumps. However, Sewage Grinder pumps are much more powerful. These pumps can grind up sewage into a slurry and pump it at a very high pressure to its destination. There a couple of applications that these pumps are normally used in. The first is to pump from a residence into a shared sewer main. The second is to pump over extremely long distances, or up over very high elevation changes.

  • Effluent and Wastewater Removal
  • Used To Pump From Homes Into Pressurized Sewer Manes
  • Used To Pump Against High Amounts of Head Pressure
  • Designed To Pump Raw Sewage
  • Designed For Use In High Pressure Applications
  • Turns Solids Into A Finely Ground Slurry
  • Includes Float Switch For Automatic Operation
  • Heavy Duty Cast Iron Design
  • Compact and Easy To Handle - Only Weighs 75lbs

Little Giant Submersible Sewage Grinder Pumps

Franklin Electric FPS IGP-A231-20 2.0 HP Grinder Pump Downloadable Documents

FileName
IGP-Series-BrochureViewDownload
