• 140 Gallon Simplex Polyethylene Pump Station with 1/3 HP Effluent Pump - Part Number 140PPT-13E

140 Gallon Simplex Polyethylene Pump Station with 1/3 HP Effluent Pump

Print

28'' x 80'' BASIN, 1/3 HP EFFLUENT PUMP, 28 FT OF HEAD, 53 GPM

This 140 gallon polyethylene pump station comes pre-assembled and ready to install with all of the components needed to install a direct burial in-ground lift station. The typical application for this package is to pump treated effluent with minimal solids from a septic tank or aerobic treatment system to a leach field or secondary treatment system.

THIS ITEM SHIPS LTL FREIGHT. PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

Built To Order Within 1-2 Business Days

$1405.00MSRP: $1879.00

Item #:140PPT-13E

Manufacturer: Septic Solutions

THIS ITEM SHIPS LTL FREIGHT.
PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

140 GALLON POLYETHYLENE TANK

  • 28'' Diameter, 80'' Tall
  • Heavy Duty Polyethylene Designed For Direct Burial
  • 24'' Diameter Polylok Access Cover
  • Risers Available To Bring Access To Grade
  • 4'' Inlet Hole with Grommet
  • 2'' SCH 40 Discharge Pipe Sealed with Grommet
  • Cord Seals For Power and Float

LITTLE GIANT 1/3 HP EFFLUENT PUMP

  • Little Giant Sewage Ejector Pump Model 6EC-CIA-RFS
  • 1/3 HP, 115VAC, 5.0A, 60Hz, 1 Phase
  • 53 GPM @ 5 ft of Head Pressure
  • Shut Off: 28 ft, Max GPM: 53
  • 1-1/2'' NPT Vertical Female Discharge, 2'' Solids Handling
  • Includes Mechanical Float Switch for Automatic Operation
  • Three Year Manufacturer's Warranty

RELATED ITEMS SOLD SEPARATELY

These items are considered optional but are often added to our pump stations:

This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.

140 Gallon Pump Station with 1/3 HP Effluent Pump Downloadable Documents

FileName
140GallonPolyTank-SpecificationViewDownload
506858_ManualViewDownload
506858_SpecViewDownload
Pump-Station-Backfill-InstructionsViewDownload
