Liberty 280HV Series 230VAC 1/2 HP Submersible Effluent Pump

70 MAX GPM, 37 FT MAX HEAD, 1-1/2" DISCHARGE, 230VAC

The Liberty 280 Series Submersible Effluent Pumps is a mid-range pump for on-site wastewater systems, liquid waste transfer, and commercial sump applications. This series features Liberty's uni-body casting and quick-disconnect power cord. Automatic operation is achieved with a wide angle mechanical float switch with a piggyback plug.

Coming Soon!

$396.00MSRP: $528.00

Item #:283HV

Manufacturer: Liberty Pumps

THIS ITEM WILL BE AVAILABLE SOON! CALL (877)-925-5132 TO BE NOTIFIED WHEN THIS ITEM IS AVAILABLE FOR PURCHASE.

Product Documents

283_Features

283_Specifications

Liberty 280 Series Specifications

Model 283HV
1/2 HP, 230VAC, 4.0A, 60 Hz
50 GPM @ 15ft of Head Pressure
Shut Off: 37ft, Max GPM: 70
1-1/2'' NPT Vertical Female Discharge, 3/4'' Solids Handling
Vortex Style Impeller
Liberty's One-Piece "Unibody" Casting
Includes Quick-Disconnect 10' Power Cord with Plug
Includes 10' Wide Angle Mechanical Float Switch with Piggyback Plug
Dimensions: 9.5'' L x 6.4'' W x 13.2'' T
Three Year Warranty

Liberty 280 Series Applications

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. - See more at: http://www.libertypumps.com/Category/effluent-pumps#sthash.s9eLcImw.dpuf

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. These pumps can handle smaller solids up to 3/4’’ in size. These units are normally used to pump discharge from a septic tank or an aerobic system to a drain field, secondary treatment system, or surface discharging point.
