• Liberty FL100-Series 1.0 HP Submersible Effluent Pump - Part Number FL102A

Liberty FL100-Series 1.0 HP Submersible Effluent Pump

Print

105 MAX GPM, 89 FT MAX HEAD, 2'' DISCHARGE

The Liberty FL100-Series Submersible Effluent Pumps provide efficient, low-cost pumping in high head on-site wastewater systems, liquid waste transfer, and commercial sump applications. Built of heavy cast iron with stainless steel fasteners for years of reliable performance. Automatic operation is achieved with a wide angle mechanical float switch with a piggyback plug.

Assembled In USAPowder Coated Tough

In Stock

$1141.50MSRP: $1522.00

Item #:FL102A

Manufacturer: Liberty Pumps

Liberty FL100-Series Specifications

  • Model FL102A
  • 1.0 HP, 208-230VAC, 12.0A, 60 Hz
  • 60 GPM @ 60ft of Head Pressure
  • Shut Off: 89ft, Max GPM: 105
  • 2'' NPT Vertical Female Discharge, 3/4'' Solids Handling
  • Vortex Impeller Made of High Temp Engineering Polymer Permits Passage of Solids without Clogging
  • Includes Quick-Disconnect 25' Power Cord with Plug
  • Includes 25' Wide Angle Mechanical Float Switch with Piggyback Plug
  • Dimensions: 11.8'' L x 8.2'' W x 18.3'' T
  • Three Year Warranty

Liberty FL100-Series Applications

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. - See more at: http://www.libertypumps.com/Category/effluent-pumps#sthash.s9eLcImw.dpuf

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. These pumps can handle smaller solids up to 3/4’’ in size. These units are normally used to pump discharge from a septic tank or an aerobic system to a drain field, secondary treatment system, or surface discharging point.

  • STEP Systems
  • LPP Systems
  • Mound Systems
  • Liquid Waste Transfer
  • Commercial Sump Applications
  • Effluent and Wastewater Removal

Liberty Submersible Sewage and Effluent Pumps

Liberty FL100-Series 1.0 HP Submersible Effluent Pump Downloadable Documents

FileName
FL100-150-200_FeaturesViewDownload
FL102A_SpecificationsViewDownload
Liberty-InstallationViewDownload
