• 120 Gallon Simplex Fiberglass Pump Station with 1/2 HP Effluent Pump - Part Number 120FPT-283

120 Gallon Simplex Fiberglass Pump Station with 1/2 HP Effluent Pump

Print

28'' x 70'' BASIN, 1/2 HP EFFLUENT PUMP, 37 FT OF HEAD, 70 GPM

This 120 gallon fiberglass pump station comes pre-assembled and ready to install with all of the components needed to install a direct burial in-ground effluent lift station. The typical application for this package is to pump treated effluent with minimal solids from a septic tank or aerobic treatment system to a leach field or secondary treatment system.

THIS ITEM SHIPS LTL FREIGHT. PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

Assembled In USA

Built To Order Within 1-2 Business Days

$1525.00MSRP: $1899.00

Item #:120FPT-283

Manufacturer: Septic Solutions

THIS ITEM SHIPS LTL FREIGHT.
PLEASE EMAIL SALES@SEPTICSOLUTIONS.COM FOR A QUOTE OR CALL (877)-925-5132 TO PLACE AN ORDER.

120 GALLON FIBERGLASS TANK

  • 28'' Diameter, 70'' Tall
  • Heavy Duty Fiberglass Designed For Direct Burial
  • 20'' Diameter Polylok Access Cover
  • Risers Available To Bring Access To Grade
  • 4'' Inlet Hole with Grommet
  • 1-1/2'' SCH 40 Discharge Pipe Sealed with Grommet
  • Cord Seals For Power and Float

LIBERTY 1/2 HP EFFLUENT PUMP

  • Model 283
  • 1/2 HP, 115VAC, 8.0A, 60 Hz
  • 50 GPM @ 15ft of Head Pressure
  • Shut Off: 37ft, Max GPM: 70
  • 1-1/2'' NPT Vertical Female Discharge, 3/4'' Solids Handling
  • Vortex Style Impeller
  • Liberty's One-Piece "Unibody" Casting
  • Includes Quick-Disconnect 10' Power Cord with Plug
  • Includes 10' Wide Angle Mechanical Float Switch with Piggyback Plug
  • Dimensions: 9.5'' L x 6.4'' W x 13.2'' T
  • Three Year Warranty

RELATED ITEMS SOLD SEPARATELY

These items are considered optional but are often added to our pump stations:

This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.

120 Gallon Pump Station with 1/2 HP Effluent Pump Downloadable Documents

FileName
120FiberglassTank_SpecViewDownload
283_SpecificationsViewDownload
Pump-Station-Backfill-InstructionsViewDownload
